Cisco Catalyst 9200 Series Switches
Roll over image to zoom in
₹ 154,999.00₹ 178,250.00 (-13%)
- Brand: Cisco Catalyst
- Certification: FCC
- Downlinks total 10/100/1000 or PoE+ copper ports: 24, 24 ports data
- Fans: Fixed redundant
- DRAM: 2 GB, 4 GB
- Flash: 4 GB, 8GB
- Max Switching capacity: 392 Gbps
- 24/7 technical support
- Fast and secure delivery
Description
Technical Specifications
| C9200L-24T-4G-E Specification | |
|---|---|
| Port Configuration | |
| Downlink Ports | 24 x 10/100/1000BASE-T or PoE+ |
| Uplink Ports | 4 x 1000BASE-T |
| Physical Specifications | |
| Dimensions (HxWxD) | 1.73 x 17.5 x 11.3 in (4.4 x 44.5 x 28.8 cm) |
| Weight | 4.35 kg |
| Power Supply | PWR-C5-125WAC |
| Fans | Fixed, Redundant |
| Performance and Scalability | |
| Switching Capacity | 56 Gbps |
| Forwarding Rate | 83.33 Mpps |
| MAC Address Table Size | 16000 |
| IPv4 Routing Entries | 3000 |
| IPv6 Routing Entries | 1500 |
| Multicast Groups | 1000 |
| QoS Queues | 1000 |
| ACL Entries | 1500 |
| Flexible NetFlow Flows | 16000 |
| VLANs | 1024 |
| SVIs | 512 |
| Jumbo Frames | 9198 bytes |
| Stacking Bandwidth | 80 Gbps |
| Memory and Storage | |
| DRAM | 2 GB |
| Flash Memory | 4 GB |
| Reliability and Availability | |
| MTBF | 531,030 hours |
| Software | |
| Operating System | Network Essentials |
Technical Specifications
| C9200L-24T-4X-E Specification | |
|---|---|
| Ports | |
| Downlink Ports | 10/100/1000 or PoE+ copper ports |
| Uplink Ports | 4x 1/10G fixed uplinks |
| Power Supply | |
| Primary AC Power Supply | PWR-C5-125WAC |
| Physical Characteristics | |
| Dimensions (HxWxD) | 4.4 x 44.5 x 28.8 cm |
| Performance | |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 190.4 Mpps |
| Stacking Bandwidth | 80 Gbps |
| Memory and Storage | |
| DRAM | 2 GB |
| Flash | 4 GB |
| Scalability | |
| Virtual Networks | 1 |
| MAC Addresses | 16000 |
| IPv4 Routes | 11000 |
| IPv4 Routing Entries | 3000 |
| IPv6 Routing Entries | 1500 |
| Multicast Routing Scale | 1000 |
| QoS Scale Entries | 1000 |
| ACL Scale Entries | 1500 |
| Flexible NetFlow (FNF) entries | 16,000 flows on 24- and 48-port Gigabit Ethernet models |
| Packet buffer per SKU | 6 MB buffers for 24- or 48-port Gigabit Ethernet models |
| VLAN IDs | 1024 |
| Total Switched Virtual Interfaces (SVIs) | 512 |
| Jumbo Frames | 9198 bytes |
| Reliability | |
| MTBF Mean time between failures (hours) | 525,990 hours |
| Software | |
| Operating System | Network Essentials |
Technical Specifications
| C9200L-48T-4X-E Specification | |
|---|---|
| Ports | |
| Downlink Ports | 10/100/1000 or PoE+ copper ports |
| Uplink Ports | 4 x 10G fixed uplinks |
| Performance | |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 130.95 Mpps |
| Stacking Bandwidth | 80 Gbps |
| Packet buffer per SKU | 6 MB buffers for 24- or 48- port Gigabit Ethernet models, 12 MB buffers for 24 or 48 port multigigabit models |
| Flexible NetFlow (FNF) entries | 16,000 flows on 24- and 48- port Gigabit Ethernet models, 32,000 flows on 24 or 48 port multigigabit models |
| Memory and Storage | |
| DRAM | 2 GB |
| Flash Memory | 4 GB |
| Scalability | |
| MAC Addresses | 16000 |
| IPv4 Routes | 11,000 (8,000 direct, 3,000 indirect) |
| IPv4 Routing Entries | 3000 |
| IPv6 Routing Entries | 1500 |
| Multicast Routing Scale | 1000 |
| QoS Scale Entries | 1000 |
| ACL Scale Entries | 1500 |
| Flexible NetFlow (FNF) Flows | 16000 |
| VLAN IDs | 1024 |
| Switched Virtual Interfaces (SVIs) | 512 |
| Jumbo Frames | 9198 bytes |
| Physical Specifications | |
| Dimensions (HxWxD) | 1.73 x 17.5 x 11.3 in (4.4 x 44.5 x 28.8 cm) |
| Power Supply | PWR-C5-125WAC |
| Fans | Fixed Redundant |
| Reliability and Availability | |
| Mean Time Between Failures (MTBF) | 503,400 hours |
Technical Specifications
| C9200L-48P-4X-A Specification | |
|---|---|
| Downlink ports | 10/100/1000 or PoE+ copper |
| Full PoE+ ports | 48 |
| Uplink configuration | 4x 1/10G fixed uplinks |
| Default primary AC power supply | PWR-C5-1KWAC |
| Fans | Fixed redundant |
| Software | Network Advantage |
| Chassis Dimensions (in) | 1.73 x 17.5 x 11.3 |
| Chassis Dimensions (cm) | 4.4 x 44.5 x 28.8 |
| Virtual Networks | 1 |
| Stacking bandwidth | 80 Gbps |
| Total number of MAC addresses | 16000 |
| Total IPv4 routes | 11000 |
| IPv4 routing entries | 3000 |
| IPv6 routing entries | 1500 |
| Multicast routing scale | 1000 |
| QoS scale entries | 1000 |
| ACL scale entries | 1500 |
| Packet buffer per SKU | 6 MB for 24- or 48-port Gigabit Ethernet models |
| Flexible NetFlow (FNF) entries | 16,000 flows on 24- and 48-port Gigabit Ethernet models |
| DRAM | 2 GB |
| Flash | 4 GB |
| VLAN IDs | 1024 |
| Total Switched Virtual Interfaces (SVIs) | 512 |
| Jumbo frames | 9198 bytes |
| Wireless bandwidth per switch | N/A |
| Switching capacity | 176 Gbps |
| Forwarding rate | 130.95 Mpps |
| Mean time between failures (hours) | 346270 |
